IP Bullet Camera 8MP AI ISP Ultra Star light Mic IBTM28P-40US
1/1.8″ SONY Sensor; NOVATEK SOC, 120dB WDR, Ultra Starvis night vision
Main Stream: 8MP@60fps, 5mp@60fps, With internal POE
Built in Mic
Smart Analytics:
Intrusion Detection, Line Cross Detectionter Area,
Leave Area(based on human and vehicle Det
Loiter Detection, People Gather Detectionetection),
Face Detection(not support other Al functection), lllegal Parking,Line Crossing Count
1/1.8″ SONY Sensor; NOVATEK SOC, 120dB WDR, Ultra Starvis night vision
Main Stream: 8MP@60fps, 5mp@60fps, With internal POE
Built in Mic
Smart Analytics:
Intrusion Detection, Line Cross Detectionter Area,
Leave Area(based on human and vehicle Det
Loiter Detection, People Gather Detectionetection),
Face Detection(not support other Al functection), lllegal Parking,Line Crossing Count
| Camera | |
| Image Sensor | 1/1.8″ SONY Starvis2 Back-illuminated CMOS sensor |
| Resolution | 8MP |
| Effective Pixels | 3856H)*2180(V) |
| Compression | H.264/H.264+/H.265/H.265+/MJPEG |
| Audio Compression | G711A/U,AAC |
| TV System | PAL/NTSC |
| Electronic Shutter Time | Auto: 1/3-1/100000Sec |
| Minimun Illumination | Color：0.0001Lux @ (F1.0, AGC ON)，0 Lux with white light |
| S/N Ratio | 60dB |
| Scanning System | Progressive |
| Video Output | Network |
| Reset Button | / |
| Lens | |
| Focal Length & FOV | 4 mm, horizontal FOV 93°, vertical FOV 49°, diagonal FOV 110° |
| Lens Type | Fixed focal lens, 4mm |
| Focus Control | Fixed |
| Aperture | F1.0 |
| Pixels | 8MP |
| Night Vision | |
| Supplement Light | Support Warm light LED 4000K, up to 25m |
| Supplement Light Distance | N/A |
| Supplement Light Status | Auto Control |
| Supplement Light Power On | Smart, Manual & Timed mode |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| Wireless | N/A |
| Protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTMP, RTCP, PPPoE, NTP, SMTP, UDP, SNMP, Qos, 802.1x |
| ONVIF | Support ONVIF 24.12(Profile S/T/G/M) |
| P2P | YES |
| POE | Internal, Support IEEE 802.3af |
| Video Delay | 0.3S (Within the Lan) |
| Main Stream 1 |
3840*2160@60fps, 3200*1600@60fps |
| Main Stream 2 | 2560*1440@60fps, 1920*1080@60fps |
| Main Stream 3 | 1280*720@60fps |
| Sub Stream 1 | 1280*720@30fps720*480@30fps |
| Sub Stream 2 | NA |
| Sub Stream 3 | NA |
| Tri Stream | 1280*720@30fps,720*480@30fps |
| IE Brower | Microsoft Edge, IE11, Google Chrome, Fire |
| Smart Phone | iPhone, Android |
| AI Function | |
| Intelligent Analysis | Intrusion Detection, Line Cross Detectionter Area, Leave Area(based on human and vehicle Det Loiter Detection, People Gather Detectionetection), Face Detection(not support other Al functection), lllegal Parking,Line Crossing Count |
| Camera Features | |
| Day/Night | Color/ B&W (IR-CUT) |
| Image Config | Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance,Anti Flicker, Video Tampering, HLC, Distortion |
| Full Color | Support |
| Corridor Pattern | Support |
| Defog Mode | Support |
| ROI | Support |
| BLC | Support |
| WDR | 120dB |
| Motion Detection | Support(support enable the detection based on human movement only) |
| Privacy Masking | 3 Rectangular Zone |
| Recording Mode | NVR/CMS/Web |
| Language | Chinese Simplified, Chinese Traditional, English, Russian, Korean, Polish, French, Japanese, Spanish, Portuguese, Italian, Hebrew, Ukrainian, Arabic, Vietnamese, Thai, Hungarian |
| Interface | |
| Audio | Built-in MIC |
| Alarm | / |
| SD Card Slot | Support Max 512GB,Built in 4G Storage |
| RS485 | N/A |
| General | |
| Housing | Metal ,IP67 |
| Anti-cut Bracket | NO |
| IR Cut Filter | YES |
| Operation Temperature | -20℃ ~ +60℃ RH95% Max |
| Storage Temperature | -20℃ ~ +60℃ RH95% Max |
| Power Source | DC12V±10%, 1000mA |
| Dimension | 268 x 95 x 88 mm |
| Weight | 1200g |
